High-Speed Efficiency
Engineered to outperform traditional power harrow/drill combinations, the Land Master operates at higher speeds with significantly lower power requirements, allowing a 150 HP tractor to comfortably manage a 6m unit.
Invest in a machine crafted for long-lasting durability and minimal maintenance, ensuring your investment stands the test of time.
Superior Power-to-Width Ratio
Operate wider implements with less horsepower for maximum field efficiency.
Reduced Soil Compaction
Fewer passes result in lower fuel consumption and protected soil structure.
All-Weather Durability
Rugged British construction designed for an extended service life and minimal downtime.
Versatile Surface Refinement
The Land Master replaces multiple passes with a single, high-intensity cultivation strategy that creates a level, firmed seedbed resulting in improved establishment. Featuring track eradicator tines and four rows of straight assisted tines, it shatters clods and cultivates the soil surface with precision. This multi-zone approach ensures that even the most stubborn land types are worked down into a fine, uniform tilth ready for immediate sowing.
Advanced Consolidation & Leveling
To ensure a weatherproof finish, the machine utilises a heavy-duty leveling board with stub teeth to manage primary furrows before the final pressing stage. The combination of double 50mm square high-tensile coils and a 20” Cambridge roller with breaker rings provides deep-action consolidation. This dual-stage pressing effectively seals in moisture and eliminates air pockets, providing the ideal environment for even crop growth and ripening.
SPECIFICATIONS
Aggressive Tine Configuration
Equipped with four rows of straight assisted tines with easy depth adjustment, the Land Master allows for precise control over your cultivation depth. Integrated track eradicator tines ensure that tractor wheelings are effectively removed, providing a uniform finish across the entire working width.
Heavy-Duty Levelling & Crushing
The front-mounted heavy-duty levelling board is fitted with stub teeth to
aggressively break down the initial furrow and manage trash. This ensures
a level surface is presented to the cultivation tines, maximising the
effectiveness of the soil-shattering process.
High-Tensile Coil System
The machine features double 50mm square high-tensile coils complete with cleaning stars to prevent clogging in damp or sticky conditions. This ‘Star’ system ensures the coils remain clear, maintaining consistent weight and consolidation performance throughout the day.
Precision Cambridge Consolidation
For the final finish, a 20” Cambridge roller with breaker rings provides the ideal level of consolidation and weatherproofing. This dual-action roller ensures the seedbed is firm enough for consistent seed placement while leaving a textured surface to resist capping.
